XGHB90E340
Electronic tag, Radio frequency identification XG, RFID 13.56 MHz, ISO badge 54 x 85.5 x 1, 256 Bytes
COMMERCIALISED
Expand all
Datasheet
Range of product
Telemecanique Radio frequency identification XG
Product or component type
Electronic tag
RFID electronic tag name
XGHB
Design
ISO badge
Memory capacity
256 B
Outer dimension
54 x 85.5 x 1 mm
Quantity per set
Set of 10
Read time
12 + 0.825 x (number of 16-bit words) ms
write time
20 + 11.8 x (number of 16-bit words) ms
IP degree of protection
IP65
Memory type
EEPROM
Memory operation
Read/write
Number of read cycles
Unlimited
Number of write cycles
100000 at -25-50 °C, 2500000 at 30-30 °C
Material
PVC (polyvinyl chloride)
Standards
ISO 15693
Vibration resistance
2 mm conforming to IEC 60068-2-6 (f = 5-29.5 Hz), 7 gn conforming to IEC 60068-2-6 (f = 29.5-150 Hz)
Shock resistance
30 gn conforming to IEC 60068-2-27 for 11 ms
IK degree of protection
IK02 conforming to IEC 62262
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
0.1 CENTIMETER
Package 1 width
5.5 CENTIMETER
Package 1 length
9 CENTIMETER
Package 1 weight
0.005 KILOGRAM
Unit type of package 2
S01
Number of units in package 2
500
Package 2 height
15 CENTIMETER
Package 2 width
15 CENTIMETER
Package 2 length
40 CENTIMETER
Package 2 weight
2.925 KILOGRAM
Unit type of package 3
S02
Number of units in package 3
50
Package 3 height
15 CENTIMETER
Package 3 width
30 CENTIMETER
Package 3 length
40 CENTIMETER
Indivisible sale quantity
10
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Expand all
Technical Drawings
Dimensions
Updatable Code Electronic Tags
Minimum Mounting Distances
Distance Between Tags
Minimum Mounting Distances in a Metal Structure
Curves
Dialogue Zones for Field Expanders
Dialogue Zones for Field Expanders
- (1) Recommended working zone.
Curves
Dialogue Zones for Field Expanders
- (1) Recommended working zone.
