XXSIDPC03Q
Ultrasonic sensors XX, ultrasonic sensor t V dc pnp XXSID
Commercialised
Expandir todos
Folha de dados
Range of product
Telemecanique Ultrasonic sensors XX
Sensor type
Ultrasonic sensor
Series name
General purpose
Sensor name
XXS
Sensor design
Cylindrical M12
Detection system
Diffuse
Material
Plastic
Type of output signal
Discrete
[Us] rated supply voltage
12...24 V DC with reverse polarity protection
Voltage drop
1 VOLT
Delay first up
20 MILLISECOND
IP degree of protection
IP67 conforming to IEC 60529
Marking
CE
Standards
IEC 60947-5-2
Product certifications
UL
Vibration resistance
+/-1 mm conforming to IEC 60068-2-6 (f = 10-55 Hz)
Shock resistance
30 gn in all 3 axes for 11 ms conforming to IEC 60068-2-27
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
8.5 CENTIMETER
Package 1 width
16.2 CENTIMETER
Package 1 length
25 CENTIMETER
Package 1 weight
43 GRAM
Unit type of package 3
S02
Number of units in package 3
50
Package 3 height
15 CENTIMETER
Package 3 width
30 CENTIMETER
Package 3 length
40 CENTIMETER
Unit type of package 2
BB1
Package 3 weight
2.59 KILOGRAM
Number of units in package 2
25
Package 2 height
8.5 CENTIMETER
Package 2 width
16.2 CENTIMETER
Package 2 length
25 CENTIMETER
Package 2 weight
1.11 KILOGRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
