XS618B3DBM12

Telemecanique Inductive proximity sensors XS

General purpose

Inductive proximity sensor

XS6

Cylindrical M18

50 mm

Fixed

Discrete

2-wire

1 NC

Flush mountable

Metal

Male connector M12, 4 pins

12...24 V DC with reverse polarity protection

DC

<= 100 mA DC with overload and short-circuit protection

IP67 conforming to IEC 60529, IP69K conforming to DIN 40050

Nickel plated brass

Frontal

M18 x 1

PPS

> 4...8 mm

1...15 % of Sr

Output state: 1 LED (yellow)

<= 1000 Hz DC

<4 V (closed)

10 MILLISECOND

0.3 MILLISECOND

CE

0.3 MILLISECOND

CSA
UL

25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conforming to IEC 60068-2-6

50 gn for 11 ms conforming to IEC 60068-2-27

PCE

1

4.1 CENTIMETER

6.4 CENTIMETER

9.4 CENTIMETER

0.06 KILOGRAM

S01

22

15 CENTIMETER

15 CENTIMETER

40 CENTIMETER

1.545 KILOGRAM

CAR

1

6.4 CENTIMETER

9.4 CENTIMETER

4.1 CENTIMETER

0.06 KILOGRAM

1
