XS9E111A1L01M12
Inductive proximity sensors XS, inductive sensor XS9 26x26x13, PBT, Sn10mm, 24 VDC, M12 0.15 m
COMMERCIALISED
Expandir todo
Ficha de datos
Range of product
Telemecanique Inductive proximity sensors XS
Series name
Application
Sensor type
Inductive proximity sensor
Device application
Not applicable
Sensor name
XS9
Sensor design
Flat form 26 x 26 x 13
Size
13 mm
Body type
Fixed
Enclosure material
PBT
Type of output signal
Analogue
Wiring technique
2-wire
Electrical connection
Remote male connector M12, 4 pins
Analogue output range
0...10 V
[Us] rated supply voltage
24 V DC
IP degree of protection
IP67 double insulation conforming to IEC 60529
Detector flush mounting acceptance
Flush mountable
Material
Plastic
Output circuit type
DC
Detection face
Frontal
Front material
PBT
Repeat accuracy
<= 3% of Sr
Linearity error
+/- 1 V
Sensing range
8...15 mm
Status LED
Without
Switching frequency
<= 1000 Hz
Output current drift
10 PERCENTAGE
Current consumption
0...4 mA no-load
Marking
CE
Product certifications
CSA
Ecolab
UL
Ecolab
UL
Shock resistance
50 gn for 11 ms conforming to IEC 60068-2-27
Vibration resistance
25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conforming to IEC 60068-2-6
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
3.4 CENTIMETER
Package 1 width
6.6 CENTIMETER
Package 1 weight
0.047 KILOGRAM
Package 1 length
8.8 CENTIMETER
Unit type of package 2
S01
Number of units in package 2
22
Package 2 height
15 CENTIMETER
Package 2 width
15 CENTIMETER
Package 2 length
40 CENTIMETER
Package 2 weight
1.21 KILOGRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Expandir todo
Dibujos tecnicos
Dimensions
Setting-up
Minimum Mounting Distances (mm)
Minimum Mounting Distances (mm)
Minimum Mounting Distances (mm)
Wiring Schemes
3-Wire Connection
3-Wire Connection
Output Curves
