9007AA0

Limit switch lever, 9007, arm

arrow

COMMERCIALISED

Download pdf datasheet Download 3d cad file Find a distributor

Expand all

Datasheet

Range of product
9007
Series name
HEAVY DUTY
Product or component type
LIMIT SWITCH LEVER
Device short name
9007C
Type of operator
Cast zinc spring return roller lever without roller length: 0.88-0.88 in - offset: - -
Type of approach
LATERAL APPROACH
Movement of operating head
ROTARY
Switch actuation
BY 30 D CAM
Positive opening
WITHOUT
Environmental characteristic
STANDARD
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
6.4520 CENTIMETER
Package 1 width
2.5400 CENTIMETER
Package 1 length
16.3870 CENTIMETER
Package 1 weight
45.3590 GRAM
