9007AW18M11
Limit switch 9007AW, 600 VAC, 10 A, option version, AW version
COMMERCIALISED
Expand all
Datasheet
Device short name
AW
Series name
Heavy duty
Body type
Deep box
Contact operation
Snap action
Body material
Cast zinc
Switch actuation
CCW
Product certifications
CE
CSA LR25490 class 3211 03
UL listed file E42259 CCN NKCR
CSA LR25490 class 3211 03
UL listed file E42259 CCN NKCR
Cable entry
-
Type of operator
-
Mounting location
-
NEMA degree of protection
NEMA 1/2/4/12/13
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
4.318 CENTIMETER
Package 1 width
7.112 CENTIMETER
Package 1 length
13.208 CENTIMETER
Package 1 weight
0.567 KILOGRAM
Unit type of package 2
S02
Number of units in package 2
8
Package 2 height
15 CENTIMETER
Package 2 width
30 CENTIMETER
Package 2 length
40 CENTIMETER
Package 2 weight
5.015 KILOGRAM
Unit type of package 3
CAR
Number of units in package 3
1
Package 3 height
21.8 CENTIMETER
Package 3 width
14.2 CENTIMETER
Package 3 length
21.8 CENTIMETER
Package 3 weight
0.57 KILOGRAM
Indivisible sale quantity
1
