9007D2
Limit switch lever, 9007, arm t+ft+options
COMMERCIALISED
Expand all
Datasheet
Range of product
9007
Series name
SEVERE DUTY
Product or component type
LIMIT SWITCH LEVER
Device short name
9007T FT
Movement of operating head
ROTARY
Type of operator
Cast zinc spring return roller lever length: 1.5-1.5 in - offset: 0.75 in -
Type of roller
1 steel outside offset roller diameter: 1 in - width: 0.25 in
Type of approach
LATERAL APPROACH
Positive opening
WITHOUT
Switch actuation
BY 30 D CAM
Environmental characteristic
STANDARD
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
6.4520 CENTIMETER
Package 1 width
2.5400 CENTIMETER
Package 1 length
16.3870 CENTIMETER
Package 1 weight
45.3590 GRAM
