9036GG2R
Float switch, Pumptrol, open tank, NEMA 1, pedestal mounted, 2 NO DPST DB contacts
Commercialized
Expand all
Datasheet
Range of produc
Pumptrol
Product or component type
Float switch
Device application
Open tank heavy duty
Device short name
9036G
Product specific application
Liquid level control
Electrical circuit type
Power circuit
Quantity per set
Set of 1
Type of packing
Individual
Product destination
For open tank or sump
Device mounting
Pedestal
Cable entry number
3 knock-outs for 1/2" conduit conforming to UL 508
Contacts type and composition
2 NO, snap action, DPST-DB, Form XX
Controlled fluid
Fresh water at specific gravity of 0.85 in or higher
Sea water at specific gravity of 0.85 in or higher
Hydraulic oil at specific gravity of 0.85 in or higher
Corrosive fluid at specific gravity of 0.85 in or higher
Sea water at specific gravity of 0.85 in or higher
Hydraulic oil at specific gravity of 0.85 in or higher
Corrosive fluid at specific gravity of 0.85 in or higher
Motor power kW
1.5 kW (2 hp) at 115 V AC, 1 phase
2.2 kW (3 hp) at 115 V AC, 3 phases
2.2 kW (3 hp) at 230 V AC, 1 phase
3.7 kW (5 hp) at 230 V AC, 3 phases
0.75 kW (1 hp) at 460 V AC, 3 phases
0.75 kW (1 hp) at 475 V AC, 3 phases
0.18 kW (0.25 hp) at 32 V DC, 3 phases
0.37 kW (0.5 hp) at 115 V DC, 3 phases
0.37 kW (0.5 hp) at 230 V DC
3.7 kW (5 hp) at 460 V AC, 1 phase
3.7 kW (5 hp) at 475 V AC, 1 phase
2.2 kW (3 hp) at 115 V AC, 3 phases
2.2 kW (3 hp) at 230 V AC, 1 phase
3.7 kW (5 hp) at 230 V AC, 3 phases
0.75 kW (1 hp) at 460 V AC, 3 phases
0.75 kW (1 hp) at 475 V AC, 3 phases
0.18 kW (0.25 hp) at 32 V DC, 3 phases
0.37 kW (0.5 hp) at 115 V DC, 3 phases
0.37 kW (0.5 hp) at 230 V DC
3.7 kW (5 hp) at 460 V AC, 1 phase
3.7 kW (5 hp) at 475 V AC, 1 phase
Electrical connection
Screw-clamp terminals, clamping capacity: 10 AWG
Contact operation
Contacts open on liquid rise
Float movement
Variable adjustable
Float position
Any
Float rod angle
Vertical
Force down to trip
16 ozf long lever
24 ozf short lever
24 ozf short lever
Force up to trip
22 ozf long lever
30 ozf short lever
30 ozf short lever
Short-circuit protection
20 A cartridge fuse, type gG
Local signalling
Without
Enclosure material
Noryl thermoplastic resin or equivalent
Operating position
Vertical position only
Electrical durability
100 cycles, operating rate <60 cyc/mn
Mechanical durability
300 cycles
Terminal block type
4 terminals
Maximum operating rate
60 cyc/mn
[Ui] rated insulation voltage
575 V conforming to UL 508
Net weight
1.01 kg
Terminals description ISO n°1
Line-load-load-line
Factory modification
Without
Kit composition
Float switch
Rod and float are to be choosen in accessories
Rod and float are to be choosen in accessories
Standards
CE
UL 508
UL 508
Ambient air temperature for operation
-30…93 °C
Ambient air temperature for storage
-30…93 °C
NEMA degree of protection
NEMA 1 conforming to UL 50
Product certifications
UL listed
CSA
CSA
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Height
9.7 cm
Package 1 Width
15.5 cm
Package 1 Length
19.6 cm
Package 1 Weight
984.3 g
Unit Type of Package 2
PAL
Number of Units in Package 2
252
Package 2 Height
101.6 cm
Package 2 Width
101.6 cm
Package 2 Length
121.92 cm
Package 2 Weight
254.919 kg
Sustainable offer status
Green Premium product
REACh Regulation
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
Mercury free
Yes
RoHS exemption information
Environmental Disclosure
Circularity Profile
Warranty
18 months
