XCMD2161L1
Limit switch, Limit switches XC Standard, XCMD, forked arm with rollers 2 tracks, 1NC+1 NO, snap, 1 m
End of commercialisation End of commercialization date : End of service date :
XCMD2161L1 is replaced by the following product:
ZCE09
Limit switch head, Limit switches XC Standard, ZCE, without lever stay put left or right actuation
Quantity : 1
Quantity : 1
Quantity : 1
Quantity : 1
Expand all
Datasheet
Range of product
Telemecanique Limit switches XC Standard
Series name
Standard format
Product or component type
Limit switch
Device short name
XCMD
Sensor design
Miniature
Material
Metal
Body material
Zamak
Head material
Zamak
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
14.288 CENTIMETER
Package 1 width
14.288 CENTIMETER
Package 1 length
14.288 CENTIMETER
Package 1 weight
317.515 GRAM
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Expand all
Technical Drawings
Dimensions
Mounting
Sweep of Connecting Cable
Mounting with Rotary Heads and Levers
Type of Cam
Setting-up with Head ZCE01 and ZCE09
Wiring Diagram
2-pole NC + NO Snap Action
