Microswitch, Limit switches XC Standard, miniature limit switch, roller lever, solder tags
End of comm. announced End of commercialization date : End of service date :
Expand all
Datasheet
Range of product
OsiSense XC
Series name
Special format
Product or component type
Microswitch
Device short name
XEP3
Detector design
Miniature, DIN 41635 A format
Head type
Plunger head
Lever material
Glass reinforced polyamide roller
stainless steel
stainless steel
Lever fixing position
B
Movement of operating head
Linear
Type of operator
Roller lever
Switch actuation
Horizontal
Type of approach
Lateral approach
Electrical connection
Solder tags
Contacts type and composition
1 C/O standard
Contact operation
Snap action
Contacts material
AgNi
Body material
Polyester
Contact code designation
B300, AC-15 (Ue = 240 V, Ie = 1.5 A) conforming to IEC 60947-5-1 appendix A, R300, DC-13 (Ue = 250 V, Ie = 0.1 A) conforming to IEC 60947-5-1 appendix A
Terminals description ISO n°1
(1-2-4)OC
IP degree of protection
IP40
Marking
CE
Standards
CURus
IEC 60947-5-1
IEC 61058
UL 1054
IEC 60947-5-1
IEC 61058
UL 1054
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
2 CENTIMETER
Package 1 width
7 CENTIMETER
Package 1 length
14 CENTIMETER
Package 1 weight
5 GRAM
Unit type of package 2
BB1
Number of units in package 2
10
Package 2 height
2 CENTIMETER
Package 2 width
7 CENTIMETER
Package 2 length
14 CENTIMETER
Package 2 weight
58 GRAM
Unit type of package 3
S01
Number of units in package 3
200
Package 3 height
15 CENTIMETER
Package 3 width
15 CENTIMETER
Package 3 length
40 CENTIMETER
Package 3 weight
1.378 KILOGRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Expand all
Technical Drawings
Dimensions
Wiring Diagram
Single-pole CO Snap Action
- 1 : Black
- 2 : Grey
- 4 : Blue
Operating Curves
- (A) Number of cycles
- (B) Current
- 1 : Resistive circuit
- 2 : Inductive circuit
