XIOT11SE5MRCL
Wireless transmitter, Dry contact LPWAN 5 years subscription included
COMMERCIALISED
Expand all
Datasheet
[Us] rated supply voltage
3.6 V nominal
Battery type
-
Electrical connection
-
Range of product
Telemecanique Cloud connected sensor XIOT
Product or component type
Wireless transmitter
Web services
Smartphone app
web server
web server
Type of license
Registration on radio network included (5 years)
Communication network type
Sigfox Europe
Mode of transmission
1 status frame per day
On change on one of the inputs
On change on one of the inputs
Acquisition speed
50 frames/day
6 frames/h
6 frames/h
Transmission rate
100 bit/s
Fixing mode
By screws
Operating distance
<= 10000 m
Directives
1999/5/EC - R&TTE directive
Product certifications
CE
Standards
EN 301-489-1
ETSI EN 300 220-2
IEC 62368-1
ETSI EN 300 220-2
IEC 62368-1
IP degree of protection
IP66
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
5 CENTIMETER
Package 1 width
21.8 CENTIMETER
Package 1 length
12.4 CENTIMETER
Package 1 weight
0 KILOGRAM
Unit type of package 2
S03
Number of units in package 2
18
Package 2 height
30 CENTIMETER
Package 2 width
30 CENTIMETER
Package 2 length
40 CENTIMETER
Package 2 weight
0 KILOGRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
