XMLG010D71
Electronic pressure sensors, Pressure sensors XM, sensor XMLG, 0.8...10 bar, G 1/4 A (male), 24 V, 0...10 V
COMMERCIALISED
Expand all
Datasheet
Range of product
Telemecanique Pressure sensors XM
Product or component type
Electronic pressure sensors
Pressure sensor type
Pressure transmitter
Pressure sensor name
XMLG
Fluid connection type
G 1/4A (male) conforming to DIN 3852-E
Controlled fluid
Air (-15-125 °C), corrosive fluid (-15-125 °C), hydraulic oil (-15-125 °C), fresh water (0-125 °C)
Type of output signal
Analogue
Analogue output function
0...10 V, 3 wires
Electrical connection
1 male connector M12, 3 pins
[Us] rated supply voltage
24 V DC (voltage limits: 11.4-33 V)
Quantity per set
Set of 1
Type of packing
Individual
Local display
Without
Electrical circuit type
Control circuit
Current consumption
20 mA
Materials in contact with fluid
Ceramic
FPM (Viton)
stainless steel type AISI 303
FPM (Viton)
stainless steel type AISI 303
Operating position
Any position
Protection type
Load short-circuit
reverse polarity
reverse polarity
Response time on output
< 2 ms
Drift of the sensitivity
+/- 0.015 % of measuring range/°C
Drift of the zero point
+/- 0.015 % of measuring range/°C
Measurement accuracy
+/- 0.3 % of the measuring range
Repeat accuracy
+/- 0.1 % of the measuring range
Scale type
Fixed differential
Standards
CE
IEC 61326-2-3
IEC 61326-2-3
Product certifications
CSA C22-2 No 14
UL 508
UL 508
Protective treatment
TC
Vibration resistance
20 gn (f= 9-2000 Hz) conforming to IEC 60028-2-6
Shock resistance
25 gn for 11 ms conforming to IEC 60068-2-27
IP degree of protection
IP66 conforming to IEC 60529, IP67 conforming to IEC 60529
NEMA degree of protection
NEMA 4
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
4.6 CENTIMETER
Package 1 width
10.6 CENTIMETER
Package 1 length
13 CENTIMETER
Package 1 weight
0.133 KILOGRAM
Unit type of package 2
S02
Number of units in package 2
12
Package 2 height
15 CENTIMETER
Package 2 width
30 CENTIMETER
Package 2 length
40 CENTIMETER
Package 2 weight
1.93 KILOGRAM
Unit type of package 3
CAR
Number of units in package 3
1
Package 3 height
13.5 CENTIMETER
Package 3 width
5 CENTIMETER
Package 3 length
10.5 CENTIMETER
Package 3 weight
0.134 KILOGRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
