XS618B1MAL2
Inductive proximity sensors XS, inductive sensor XS6 M18, L62mm, brass, Sn8mm, 24...240VAC/DC, cable 2 m
COMMERCIALISED
Expand all
Datasheet
Range of product
TE INDTIVE PROX SSRS XS
Series name
GENERAL PURPOSE
Sensor type
INDUCTIVE PROXIMITY SENSOR
Sensor name
XS6
Sensor design
CYLINDRICAL M18
Size
62 MM
Body type
FIXED
Type of output signal
DISCRETE
Wiring technique
2 WIRE
Discrete output function
1 NO
Detector flush mounting acceptance
FLUSH MOUNTABLE
Material
METAL
Electrical connection
Cable
[Us] rated supply voltage
24...240 V AC/DC 50/60 Hz
Output circuit type
AC DC
Switching capacity in mA
5...200 mA DC,
5...300 mA AC
5...300 mA AC
IP degree of protection
IP68 double insulation conforming to IEC 60529,
IP69K conforming to DIN 40050
IP69K conforming to DIN 40050
Enclosure material
NICKEL PLATED BRASS
Detection face
FRONTAL
Thread type
M18 X 1
Front material
PPS
Sensing range
4 8 MM
Differential travel
1 15 PT OF SR
Cable composition
2 X 0 34 MM2
Residual current
0.8 mA open state
Status LED
Output state: 1 LED (yellow)
Wire insulation material
PVC
Switching frequency
<= 1000 Hz DC,
<= 25 Hz AC
<= 25 Hz AC
Voltage drop
<5.5 V (closed)
Delay first up
25.0000 MILLISECOND
Delay response
0.5000 MILLISECOND
Marking
CE
Delay recovery
0.5000 MILLISECOND
Product certifications
CSA
UL
UL
Vibration resistance
25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conforming to IEC 60068-2-6
Shock resistance
50 gn for 11 ms conforming to IEC 60068-2-27
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
4.2000 CENTIMETER
Package 1 width
9.7000 CENTIMETER
Package 1 length
13.2000 CENTIMETER
Package 1 weight
105.0000 GRAM
Unit type of package 2
S03
Number of units in package 2
44
Package 2 height
30.0000 CENTIMETER
Package 2 width
30.0000 CENTIMETER
Package 2 length
40.0000 CENTIMETER
Package 2 weight
5.2000 KILOGRAM
Unit type of package 3
P06
Number of units in package 3
352
Package 3 height
75.0000 CENTIMETER
Package 3 width
60.0000 CENTIMETER
Package 3 length
80.0000 CENTIMETER
Package 3 weight
56.4440 KILOGRAM
