XS8C1A1PAL2
Inductive proximity sensors XS, inductive sensor XS8 40x40x15, PBT, Sn25mm, 12...24 VDC, cable 2 m
COMMERCIALISED
Expand all
Datasheet
Range of product
TE INDTIVE PROX SSRS XS
Series name
GENERAL PURPOSE
Sensor type
INDUCTIVE PROXIMITY SENSOR
Device application
NOT APPLICABLE
Sensor name
XS8
Sensor design
FLAT FORM 40 X 40 X 15
Size
15 MM
Body type
FIXED
Enclosure material
PBT
Type of output signal
DISCRETE
Wiring technique
3 WIRE
Discrete output function
1 NO
Electrical connection
Cable
Discrete output type
PNP
[Us] rated supply voltage
12...24 V DC with reverse polarity protection
IP degree of protection
IP68 double insulation conforming to IEC 60529
Switching capacity in mA
<= 200 mA DC with overload and short-circuit protection
Detector flush mounting acceptance
NON FLUSH MOUNTABLE
Material
PLASTIC
Output circuit type
DC
Detection face
FRONTAL
Front material
PBT
Differential travel
1 15 PT OF SR
Wire insulation material
PVC
Cable composition
3 X 0 34 MM2
Switching frequency
<= 1000 Hz
Residual current
1.5 mA open state
Current consumption
<= 10 mA no-load
Voltage drop
-
Delay first up
10.0000 MILLISECOND
Marking
CE
Delay response
0.3000 MILLISECOND
Voltage drop
<2 V (closed)
Delay recovery
0.8000 MILLISECOND
Product certifications
CSA
ECOLAB
UL
ECOLAB
UL
Shock resistance
-
Vibration resistance
25 gn amplitude = +/- 2 mm (f = 10-55 Hz) conforming to IEC 60068-2-6
Shock resistance
50 gn for 11 ms conforming to IEC 60068-2-27
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
4.2000 CENTIMETER
Package 1 width
9.6000 CENTIMETER
Package 1 weight
131.0000 GRAM
Package 1 length
13.2000 CENTIMETER
Unit type of package 2
S03
Number of units in package 2
44
Package 2 height
30.0000 CENTIMETER
Package 2 width
30.0000 CENTIMETER
Package 2 length
40.0000 CENTIMETER
Package 2 weight
6.2580 KILOGRAM
