XSDC507139
Inductive proximity sensors XS, inductive sensor XSD 80x80x40, plastic, Sn50mm, 12...48 VDC, terminals
Commercialised
Expand all
Datasheet
Range of product
Telemecanique Inductive proximity sensors XS
Series name
General purpose
Sensor type
Inductive proximity sensor
Product specific application
Not applicable
Sensor name
XSD
Sensor design
Form 80 x 80 x 40
Size
40 mm
Body type
Fixed
Type of output signal
Discrete
Wiring technique
2-wire
Enclosure material
Plastic
Discrete output function
1 NO
Electrical connection
Screw-clamp terminals
[Us] rated supply voltage
12...48 V DC
Switching capacity in mA
1.5...100 mA
IP degree of protection
IP67
Detector flush mounting acceptance
Non flush mountable
Material
Plastic
Output circuit type
DC
Detection face
Frontal
Cable entry
1 entry tapped for Pg 13.5 cable gland
Sensing range
> 40...60 mm
Front material
Plastic
Switching frequency
<= 180 Hz
Marking
CE
Product certifications
CCC
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
5.5 CENTIMETER
Package 1 width
15 CENTIMETER
Package 1 length
9 CENTIMETER
Package 1 weight
502 GRAM
Unit type of package 2
S02
Number of units in package 2
11
Package 2 height
15 CENTIMETER
Package 2 width
30 CENTIMETER
Package 2 length
40 CENTIMETER
Package 2 weight
5.895 KILOGRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
