XUSL4E30H181LWH

PMMA (polymethyl methacrylate): tube, stainless steel AISI 316L: sealing plug, PVC (polyvinyl chloride): cable

Telemecanique Safety light curtains XUSL

XUSL4E

Safety light curtain type 4

For hand protection

2 safety outputs OSSD solid-state PNP (arc suppression)

Red RAL 3000

Long distance

By fixing brackets

Transmitter-receiver system

With heating system

Type 4 conforming to IEC 61496-1, SIL 3 conforming to IEC 61508, SILCL 3 conforming to IEC 62061, category 4 conforming to ISO 13849-1, PL = e conforming to ISO 13849-1

24 V

Automatic
manual

IP69K

Selected by wiring

DC

adjustable mounting bracket(s), 1 receiver(s), 1 transmitter(s), 1 user guide with certificate of conformity on CD-ROM, silicone o-ring(s), 1 PVC cable(s)

CE
cULus
Ecolab
TÜV

1 male connector M12 5 pins transmitter, 1 male connector M12 8 pins receiver

22 ms

CE

IR LED 950 nm

24 V DC +/- 20 %

Power supply conforming to IEC 61496-1, power supply conforming to IEC 60204-1

42 mA no-load transmitter, 83 mA no-load receiver, 42 mA transmitter, 900 mA with maximum load receiver

0.35 +/- 0.05 mm (f= 10-55 Hz) conforming to IEC 61496-1

<0.5 V

1 multi-colour LED transmitter, 2 dual colour LEDs receiver

Unshielded cable AWG 22 10-10 m

Test, muting through external safety module XPSLCMUT1160, LED display of operating modes and faults, anti-condensation system

10 gn for 16 ms conforming to IEC 61496-1

89/336/EEC - electromagnetic compatibility
89/655/EEC - work equipment
98/37/EEC - machinery

Resistance to light disturbance conforming to IEC 61496-2

PCE

1

14 CENTIMETER

20 CENTIMETER

190 CENTIMETER

9.5 KILOGRAM

14 CENTIMETER

20 CENTIMETER

190 CENTIMETER

9.5 KILOGRAM

1
