XUY40330400
XUY photoelectric conveyor system sensor
COMMERCIALISED
Expand all
Datasheet
Range of product
Telemecanique Photoelectric sensors XU
Series name
Application
Electronic sensor type
Photo-electric sensor
Sensor name
XUY
Sensor design
Fiber design
Detection system
Through beam
Sensing range
> 0...0.1 m
Material
Metal
Type of output signal
Discrete
Supply circuit type
DC
Wiring technique
3-wire
Discrete output type
PNP or NPN
Discrete output function
1 NO or 1 NC programmable
Electrical connection
1 remote male connector M12, 4 pins
Product specific application
Conveyor system
Emission
-
Enclosure material
Aluminium
Lens material
Glass
Cover material
PVC
Output type
Solid state
[Us] rated supply voltage
-
Status LED
-
Voltage drop
<2 V at 100 mA (closed state)
Switching capacity in mA
100 mA (overload and short-circuit protection)
Current consumption
< 35 mA no-load
Delay response
1 ms
Supply voltage limits
18-30 V DC
IP degree of protection
IP50 conforming to IEC 60529
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
4 CENTIMETER
Package 1 width
22.4 CENTIMETER
Package 1 length
37 CENTIMETER
Package 1 weight
0.517 KILOGRAM
Unit type of package 2
S04
Number of units in package 2
20
Package 2 height
30 CENTIMETER
Package 2 width
40 CENTIMETER
Package 2 length
60 CENTIMETER
Package 2 weight
11.32 KILOGRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
