XUYF953002COS
Photoelectric sensors XU, XUY, fork, 2X40mm, 12...24 VDC, M8
COMMERCIALISED
Expand all
Datasheet
Range of product
Telemecanique Photoelectric sensors XU
Sensor name
XUY
Series name
Application
Product specific application
Control of tools travel
detection of marks on a translucent film
detection of sheets overlapping
detection on a labelling machine
lateral shift control of a belt
lift cage position control
detection of marks on a translucent film
detection of sheets overlapping
detection on a labelling machine
lateral shift control of a belt
lift cage position control
Enclosure material
Painted aluminium strong housing
Electronic sensor type
Photo-electric sensor
Sensor design
Fork
Electrical connection
1 male connector M8, 4 pins
Material
Metal
Wiring technique
4-wire
Detection system
Thru beam
Emission
Infrared, continuous
[Us] rated supply voltage
12...24 V DC with reverse polarity protection
Type of output signal
Discrete
Supply circuit type
DC
Discrete output type
PNP/NPN
Current consumption
40 mA no-load
Output type
Solid state
Switching capacity in mA
100 mA (overload and short-circuit protection)
Voltage drop
<1 V at 10 mA (closed state), <2 V at 100 mA (closed state)
Maximum delay recovery
-
IP degree of protection
IP65 conforming to IEC 60529
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
3.4 CENTIMETER
Package 1 width
7.4 CENTIMETER
Package 1 length
13 CENTIMETER
Package 1 weight
0.055 KILOGRAM
Unit type of package 2
S01
Number of units in package 2
15
Package 2 height
15 CENTIMETER
Package 2 width
15 CENTIMETER
Package 2 length
40 CENTIMETER
Package 2 weight
0.996 KILOGRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
