XY2CE2A250EX
Latching emergency stop trip wire switch, Telemecanique Emergency stop rope pull switches XY2C, rope pull with light force, LH side, 1NC+1NO
COMMERCIALISED
Expand all
Datasheet
Housing colour
-
Connections - terminals
-
Safety level
Can reach PL = e with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach category 4 with the appropriate monitoring system and correctly wired conforming to ISO 13849-1, can reach SIL 3 conforming to IEC 61508
Safety reliability data
B10d = 300000 value given for a life time of 20 years limited by mechanical or contact wear
Positive opening
-
Resistance across terminals
25 MOhm conforming to IEC 60255-7 category 3, 25 MOhm conforming to NF C 93-050 method A
Vibration resistance
10 gn (f= 10-300 Hz) conforming to IEC 60068-2-6
Shock resistance
-
IP degree of protection
IP65
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
9.5 CENTIMETER
Package 1 width
17.5 CENTIMETER
Package 1 length
22 CENTIMETER
Package 1 weight
1.592 KILOGRAM
Unit type of package 2
S03
Number of units in package 2
6
Package 2 height
30 CENTIMETER
Package 2 width
30 CENTIMETER
Package 2 length
40 CENTIMETER
Unit type of package 3
CAR
Package 2 weight
10.058 KILOGRAM
Number of units in package 3
1
Package 3 height
21.5 CENTIMETER
Package 3 width
10 CENTIMETER
Package 3 length
17.5 CENTIMETER
Package 3 weight
1.573 KILOGRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Expand all
Technical Drawings
Dimensions
- (1) 3 plain holes for Pg 13.5 cable gland.
- (2) Maximum extension.
- Ø 4 elongated holes Ø 6 mm/0.24 in.
Electrical Curves
AC Supply 50/60 Hz Inductive Circuit
- Y Millions of operating cycles
- X Current in A
Electrical Curves
