XS1M18PAW01D

Inductive sensor XS1 M18 - L60mm - brass - Sn5mm - 12..24VDC - M12

End of commercialisation Fecha de fin de comercialización : Fecha de fin del servicio :

Descargar hoja de datos en pdf Descargar archivo CAD 3D Encontrar un distribuidor

XS1M18PAW01D is replaced by the following product:

XS918RWPAM12

Inductive proximity sensors XS, inductive sensor XS9 M18, L64mm, full SS 303, Sn10 mm, 12...24 VDC, M12

Quantity :  1

Expandir todo

Ficha de datos

Range of product
Telemecanique Inductive proximity sensors XS
Series name
Application
Sensor type
Inductive proximity sensor
Device application
Welding machine
Sensor name
XS1
Sensor design
Cylindrical M18
Size
60 mm
Body type
Fixed
Type of output signal
Discrete
Wiring technique
3-wire
Enclosure material
Nickel plated brass
Discrete output function
1 NO
Discrete output type
PNP
Electrical connection
Male connector M12, 4 pins
[Us] rated supply voltage
12...24 V DC with reverse polarity protection
Switching capacity in mA
<= 250 mA with overload and short-circuit protection
IP degree of protection
IP67 conforming to IEC 60529
Detector flush mounting acceptance
Flush mountable
Material
Metal
Output circuit type
DC
Detection face
Frontal
Thread type
M18 x 1
Sensing range
> 4...8 mm
Front material
Teflon
Differential travel
1...20 % of Sr
Repeat accuracy
3 % of Sr
Status LED
Output state: 1 LED (yellow)
Switching frequency
<= 500 Hz
Voltage drop
<2.5 V (closed)
Current consumption
<= 15 mA no-load
Delay first up
10 MILLISECOND
Delay response
0.2 MILLISECOND
Marking
CE
Delay recovery
0.6 MILLISECOND
Product certifications
CSA
UL
Unit type of package 1
PCE
Number of units in package 1
1
