7XJ1N
Limit switch lever, 9007, ms+ml +options
Commercialized
Expand all
Datasheet
Range of produc
9007
Series name
Miniature potted
Product or component type
Limit switch lever
Device short name
9007MS/ML
Associated complete product
9007ML04..
9007MS04..
9007MS04..
Movement of operating head
Rotary
Type of operator
Cast zinc spring return roller lever length: 38.10 mm -
Type of roller
1 nylon inside roller diameter: 19.05 mm - width: 25.40 mm
Type of approach
Lateral approach
Positive opening
Without
Tracks
0.875 in
Switch actuation
By 30° cam
Net weight
0.05 kg
Ambient air temperature for operation
-40…105 °C
Ambient air temperature for storage
-40…105 °C
Environmental characteristic
Standard environment
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Height
3.3 cm
Package 1 Width
10.2 cm
Package 1 Length
17.8 cm
Package 1 Weight
36.3 g
REACh Regulation
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
Mercury free
Yes
RoHS exemption information
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Warranty
18 months
