ZMLPA1P2SW
Switch with display, ZMLP, output 4-20 mA + PNP, 24 VDC, window mode, M12 connector
COMMERCIALISED
Expand all
Datasheet
Range of product
OsiSense XM
Product or component type
Electronic pressure sensors
Device short name
ZMLP
ETIM classification
ETIM 9 - EC002594 - Accessories/spare parts for position switches
Front material
Polyester
Housing material
PBT Valox
Operating position
Any position
Display type
4 digits 7 segments
Product certifications
cULus
Marking
CE
Standards
IEC 61000-6-2
IEC 61000-6-4
UL 508
IEC 61000-6-4
UL 508
Indivisible sale quantity
1
Mechanical durability
10000000 cycles
Electrical connection
Female connector M12, 2 pins, male connector M12, 4 pins
[Us] rated supply voltage
24 V DC SELV (voltage limits: 17-33 V)
[Uimp] rated impulse withstand voltage
0.5 kV DC
Maximum switching current
200 mA
Voltage drop
2 V
Current consumption
<= 50 mA
Response time
300 ms
Display range
-14.5...6000
Switching function
Window
Protection type
Overload protection
overvoltage protection
reverse polarity
short-circuit protection
overvoltage protection
reverse polarity
short-circuit protection
Local signalling
1 LED (yellow) for light ON when switch is actuated
Type of output signal
Analogue + discrete
Adjustable range of switching point on rising pressure
5-98 % of selected display range
Adjustable range of switching point on falling pressure
2-95 % of selected display range
Minimum differential travel
3 % of selected display range
Analogue output function
4...20 mA
Discrete output type
Solid state PNP, NO/NC programmable
Response time on output
<= 3 ms for analog output, <= 3 ms for discrete output
Delay first up
100 ms
Measurement accuracy
<= 1 % of the measuring range
Accuracy
<= - 0.1 % of the measuring range
Display accuracy
<= 1 % of the measuring range
Height
77 mm
Width
41 mm
Depth
42 mm
Product weight
0.103 kg
IP degree of protection
IP67 conforming to IEC 60529, IP65 conforming to IEC 60529, IP69K conforming to DIN 40050
Ambient air temperature for operation
-25…70 °C
Ambient air temperature for storage
-30…80 °C
Shock resistance
25 gn conforming to IEC 60068-2-27
Vibration resistance
5 gn (f= 10-2000 Hz) conforming to IEC 60068-2-6
Electromagnetic compatibility
Immunity to conducted RF disturbances: 10 V 0.15...80 MHz conforming to IEC 61000-4-6, surge immunity test: 1 kV conforming to IEC 61000-4-5, electrical fast transient/burst immunity test: 2 kV conforming to IEC 61000-4-4, susceptibility to electromagnetic fields: 10 V/m 80...2000 MHz conforming to IEC 61000-4-3, electrostatic discharge immunity test: 8 kV air, 4 kV contact conforming to IEC 61000-4-2
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Warranty
18 months
Country of origin
FR (France)
Unit type of package 1
PCE
Number of units in package 1
1
New Package 1 GTIN-13
3666916060773
Package 1 height
4.9 cm
Package 1 width
9.1 cm
Package 1 length
4.3 cm
Package 1 weight
0.104 kg
Unit type of package 2
S01
Number of units in package 2
24
New Package 2 GTIN 14
13666916060770
Package 2 height
15 cm
Package 2 width
15 cm
Package 2 length
40 cm
Package 2 weight
2.707 kg
New Package 3 GTIN 14
23666916060777
Expand all
Technical Drawings
Dimensions
Dimensions
Switch with Metal Bracket for Fixing Horizontally
Dimensions
Switch with Metal Bracket for Fixing Vertically or on an Inlet Pipe
Connections and Schema
Output M12 Male Connector Wiring
- (1) Out
- (2) I Out
Connections and Schema
Input M12 Female Connector Wiring
- (1) l in = 4-20 mA
Analog Output Description
- X : Pressure
- Y : Analog output signal
Switching Output Description. Window Mode
- X : Time
- Y : Pressure
- (1) Output
- NP : Nominal pressure
- FH : High switching point (adjustable from 5 % to 98 % NP)
- FL : Low switching point (adjustable from 2 % to 95 % NP)
