XMLP006GD21F
Pressure sensor, XMLP, pressure range 6 bar, output 4-20 mA, G1/4A male, M12 connector, FPM seal
COMMERCIALISED
Expand all
Datasheet
Range of product
Telemecanique Pressure sensors XM
Pressure sensor type
Pressure transmitter
Product or component type
Electronic pressure sensors
Pressure sensor name
XMLP
ETIM classification
ETIM 9 - EC000243 - Pressure switch
Materials in contact with fluid
Ceramic
fluorocarbon FPM
stainless steel AISI 316L
fluorocarbon FPM
stainless steel AISI 316L
Operating position
Any position
Maximum permissible accidental pressure
18 Bar
Destruction pressure
24 Bar
Controlled fluid
Fresh water (0-125 °C), air (-15-125 °C), gas (-15-125 °C), hydraulic oil (-15-125 °C)
Fluid connection type
G 1/4A (male) conforming to DIN 3852-E
Local display
Without
Diameter
26 mm
Product certifications
CE
cULus
RCM
cULus
RCM
Standards
IEC 61326-2-3
NSF ANSI 61
NSF ANSI 61
Indivisible sale quantity
1
Quantity per set
Set of 1
Type of packing
Individual
Mechanical durability
10000000 cycles
Repeat accuracy
+/- 0,25 % de la plage de mesure
Electrical connection
1 male connector M12 4 pins
Electrical circuit type
Control circuit
[Us] rated supply voltage
12...24 V DC SELV (voltage limits: 7-33 V)
[Uimp] rated impulse withstand voltage
0.5 kV
Current consumption
< 23 mA
Protection type
Load short-circuit
reverse polarity
reverse polarity
Type of output signal
Analogue
Analogue output function
4...20 mA, 2-wire
Response time on output
<= 2 ms 10...90 % of full scale
Measurement accuracy
+/- 0,5 % de la plage de mesure
Accuracy
0.1 % of the measuring range
Drift of the sensitivity
+/- 0,02 % of measuring range/°K
Drift of the zero point
+/- 0,02 % of measuring range/°K
Length
32.3 mm
Product weight
0.075 kg
IP degree of protection
IP65 conforming to IEC 60529, IP67 conforming to IEC 60529, IP69K conforming to DIN 40050
Ambient air temperature for operation
-30…85 °C
Ambient air temperature for storage
-50…100 °C
Shock resistance
100 gn for 11 ms conforming to IEC 60068-2-27
Vibration resistance
20 gn (f = 10-2000 Hz) conforming to IEC 60068-2-6
Electromagnetic compatibility
Susceptibility to electromagnetic fields conforming to IEC 61000-4-3 10 V/m 80...1000 MHz, radiated RF fields conforming to IEC 61000-4-6 10 V 0.15...80 MHz, electrostatic discharge immunity test conforming to IEC 61000-4-2 8 kV air, 4 kV contact, 1.2/50 µs shock waves immunity test conforming to IEC 61000-4-5 1 kV 42 Ohm, immunity to magnetic fields conforming to IEC 61000-4-8 100 A/m 50 Hz, electrical fast transient/burst immunity test conforming to IEC 61000-4-4 4 kV
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Warranty
18 months
Country of origin
CH (Switzerland)
Unit type of package 1
PCE
Number of units in package 1
1
New Package 1 GTIN-13
3666916022245
Package 1 height
4.2 cm
Package 1 width
4.4 cm
Package 1 length
8.4 cm
Package 1 weight
0.08 kg
Unit type of package 2
S01
Number of units in package 2
24
New Package 2 GTIN 14
13666916022242
Package 2 height
15 cm
Package 2 width
15 cm
Package 2 length
40 cm
Package 2 weight
2.181 kg
Unit type of package 3
S03
Number of units in package 3
120
New Package 3 GTIN 14
23666916022249
Package 3 height
30 cm
Package 3 width
30 cm
Package 3 length
40 cm
Expand all
Technical Drawings
Dimensions
- (1) SW24 tightening torque ≤ 25 N.m / 221 lb-in
Connection and Schema
Wiring Diagram
- (a) I out
Performance Curves
Curves
