XF9F1852
Overtravel limit switches, XR and XF, power switch, automatic reset, 3P, 185 A, 3P scheme
End of commercialisation End of commercialization date : End of service date :
Expand all
Datasheet
Range of product
XR and XF
Product or component type
Overtravel limit switches
Device short name
XF9
Electrical circuit type
Power circuit
Product specific application
Safety of hoisting equipment
Material
Sheet steel: enclosure
Type of operator
Operating lever, with counterweights
Reset
Automatic reset
Switch actuation
Horizontal and vertical approach
Contacts type and composition
Without auxiliary contact block
Contact operation
Snap action
Cable entry
2 entries tapped for Pg 36 cable gland
Standards
IEC 158-1
IEC 947-1
IEC 947-4
NF C 63-110
VDE 0660
IEC 947-1
IEC 947-4
NF C 63-110
VDE 0660
Protective treatment
TC
IP degree of protection
IP43 conforming to IEC 60529
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
42.5 CENTIMETER
Package 1 width
46 CENTIMETER
Package 1 length
62 CENTIMETER
Package 1 weight
28.537 KILOGRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
