XS7T4DA214LD01
inductive sensor XS7 40x40x40 - plastic - Sn15mm - 12..48VDC - M12
END OF COMMERCIALISATION 下架日期 : August 01st 2023 终止服务日期 : August 01st 2023
展开全部
参数资料
Range of product
Telemecanique Inductive proximity sensors XS
Series name
General purpose
Sensor type
Inductive proximity sensor
Product specific application
Not applicable
Sensor name
XS7
Sensor design
Cubic form 40 x 40 x 40
Size
40 mm
Body type
Fixed
Type of output signal
Discrete
Wiring technique
2-wire
Enclosure material
Plastic
Discrete output function
1 NO
Electrical connection
Remote male connector M12, 4 pins
[Us] rated supply voltage
12...48 V DC with reverse polarity protection
Switching capacity in mA
1.5...100 mA with overload and short-circuit protection
IP degree of protection
IP67 conforming to IEC 60529
Detector flush mounting acceptance
Flush mountable
Material
Plastic
Output circuit type
DC
Sensing range
8...15 mm
Front material
Plastic
Differential travel
3...20% of Sr
Repeat accuracy
<= 3% of Sr
Status LED
Output state: 1 LED (yellow)
Switching frequency
<= 150 Hz
Residual current
0.7 mA open state
Voltage drop
<5.2 V (closed)
Delay first up
5 MILLISECOND
Delay response
2 MILLISECOND
Marking
CE
Delay recovery
5 MILLISECOND
Product certifications
CCC
CSA
UL
CSA
UL
Unit type of package 1
PCE
Number of units in package 1
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. Fo more information go to www.P65Warnings.ca.gov
