ZCE1A
Limit switch head, Limit switches XC Standard, ZCE, metal end plunger with silicone boot
Commercialized
Expand all
Datasheet
Range of product
Telemecanique Limit switches XC Standard
Series name
Standard format
Product or component type
Limit switch head
Device short name
ZCE
Head type
Plunger head
Product compatibility
XCMD
XCKT
XCKD
XCKP
XCKT
XCKD
XCKP
Associated body
ZCT28N12
ZCMD21M12
ZCT21N12
ZCD25
ZCP29
ZCP31
ZCP26
ZCD26
ZCP21
ZCMD81L2
ZCMD81L1
ZCT25P16
ZCMD29L5
ZCP39
ZCMD39L2
ZCT26N12
ZCT25G11
ZCMD29C12
ZCMD29L2
ZCMD25L2
ZCT27N12
ZCMD41L1
ZCMD37L1
ZCD31
ZCMD81L5
ZCMD61C12
ZCMD41L2
ZCT28G11
ZCT26G11
ZCMD61M12
ZCMD21L08R12
ZCMD25L5
ZCMD25L1
ZCD21
ZCMD37L2
ZCT27G11
ZCMD29L1
ZCD37
ZCT28P16
ZCMD21L5
ZCT21P16
ZCP29M12
ZCD29M12
ZCP35
ZCD39
ZCMD69C12
ZCMD41L5
ZCMD39L5
ZCT21G11
ZCMD37L5
ZCD35
ZCP28
ZCMD21C12
ZCMD21L2
ZCMD39L1
ZCP27
ZCT26P16
ZCP37
ZCMD21L1
ZCT25N12
ZCD29
ZCP21M12
ZCP25
ZCD21M12
ZCT27P16
ZCD27
ZCD28
ZCMD21L08U78
ZCMD21M12
ZCT21N12
ZCD25
ZCP29
ZCP31
ZCP26
ZCD26
ZCP21
ZCMD81L2
ZCMD81L1
ZCT25P16
ZCMD29L5
ZCP39
ZCMD39L2
ZCT26N12
ZCT25G11
ZCMD29C12
ZCMD29L2
ZCMD25L2
ZCT27N12
ZCMD41L1
ZCMD37L1
ZCD31
ZCMD81L5
ZCMD61C12
ZCMD41L2
ZCT28G11
ZCT26G11
ZCMD61M12
ZCMD21L08R12
ZCMD25L5
ZCMD25L1
ZCD21
ZCMD37L2
ZCT27G11
ZCMD29L1
ZCD37
ZCT28P16
ZCMD21L5
ZCT21P16
ZCP29M12
ZCD29M12
ZCP35
ZCD39
ZCMD69C12
ZCMD41L5
ZCMD39L5
ZCT21G11
ZCMD37L5
ZCD35
ZCP28
ZCMD21C12
ZCMD21L2
ZCMD39L1
ZCP27
ZCT26P16
ZCP37
ZCMD21L1
ZCT25N12
ZCD29
ZCP21M12
ZCP25
ZCD21M12
ZCT27P16
ZCD27
ZCD28
ZCMD21L08U78
Movement of operating head
Linear
Type of operator
End plunger spring return metal (with silicone boot)
Type of approach
Vertical approach, 1 direction
Positive opening
With
Ambient air temperature for operation
-25…70 °C
Ambient air temperature for storage
-40…70 °C
Environmental characteristic
Standard environment
Unit Type of Package 1
PCE
Number of Units in Package 1
1
Package 1 Height
2.0 cm
Package 1 Width
3.0 cm
Package 1 Length
4.5 cm
Package 1 Weight
14.0 g
Sustainable offer status
Green Premium product
REACh Regulation
EU RoHS Directive
Pro-active compliance (Product out of EU RoHS legal scope)
Mercury free
Yes
RoHS exemption information
Circularity Profile
No need of specific recycling operations
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
Warranty
18 months
