ZCMC25L5

Pre cabled connection, Limit switches XC Standard, ZCMC, 2 Poles, PvR, 5 m

arrow

COMMERCIALISED

Download pdf datasheet Download 3d cad file Find a distributor

Expand all

Datasheet

Range of product
Telemecanique Limit switches XC Standard
Product or component type
Pre-cabled connection
Component name
ZCMC
Contacts type and composition
1 NC + 1 NO
Contact operation
Slow-break, break before make
Product compatibility
XCMD25
Electrical connection
Cable
Wire insulation material
PvR
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
4 CENTIMETER
Package 1 width
20 CENTIMETER
Package 1 length
19 CENTIMETER
Package 1 weight
0.427 KILOGRAM
Unit type of package 2
S03
Number of units in package 2
25
Package 2 height
30 CENTIMETER
Package 2 width
30 CENTIMETER
Package 2 length
40 CENTIMETER
Package 2 weight
11.388 KILOGRAM
Unit type of package 3
BAG
Number of units in package 3
1
Package 3 height
4 CENTIMETER
Package 3 width
20 CENTIMETER
Package 3 length
19 CENTIMETER
Package 3 weight
0.427 KILOGRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
