XCSC702EX
Safety switch, Telemecanique Safety switches XCS, metal key operated XCSA, 2NC + NO slow break, ATEX/IECEx
Commercialised
Espandi selezione
Datasheet
Range of product
Telemecanique Safety switches XCS
Product or component type
Safety switch
Device short name
XCSC
Material
Metal
Head type
Key operated turret head
Electrical connection
Terminal
Clamping connection capacity
1 x 0.5...2 x 1.5 mm² with or without cable end
Contacts type and composition
2 NC + 1 NO
Contact operation
Slow-break, break before make
Positive opening
With NC contact
Locking options description
With locking of actuator, unlocking by key operated lock
Local signalling
Without
Contact code designation
A300, AC-15 (Ue = 120 V, Ie = 6 A) conforming to EN/IEC 60947-5-1, A300, AC-15 (Ue = 240 V, Ie = 3 A) conforming to EN/IEC 60947-5-1, Q300, DC-13 (Ue = 125 V, Ie = 0.55 A) conforming to EN/IEC 60947-5-1, Q300, DC-13 (Ue = 250 V, Ie = 0.27 A) conforming to EN/IEC 60947-5-1
Actuator force for extraction
20 NEWTON
Operating rate
10 cyc/mn for maximum durability
Body material
Zamak
Head material
Zamak
Safety level
Can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to IEC 61508
Safety reliability data
B10d = 5000000 value given for a life time of 20 years limited by mechanical or contact wear
Protective treatment
TC
Vibration resistance
5 gn (f= 10-500 Hz) conforming to IEC 60068-2-6
Shock resistance
10 gn for 11 ms conforming to IEC 60068-2-27
Electrical shock protection class
Class I conforming to EN/IEC 60536
IP degree of protection
IP67 conforming to EN/IEC 60529 and EN/IEC 60947-5-1
Marking
II2 D-Ex tb IIIC T85°C Db IP67
Dust zone
Zone 21 - 22
Product certifications
IEC-Ex INE 17.0020X
INERIS 04ATEX0014X
INERIS 04ATEX0014X
Standards
EN/IEC 60079-0
EN/IEC 60079-31
EN/IEC 60079-31
Directives
2014/34/EU - ATEX directive
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
8.5 CENTIMETER
Package 1 width
8.8 CENTIMETER
Package 1 length
15.2 CENTIMETER
Package 1 weight
0.553 KILOGRAM
Unit type of package 2
S03
Number of units in package 2
32
Package 2 height
30 CENTIMETER
Package 2 width
30 CENTIMETER
Package 2 length
40 CENTIMETER
Package 2 weight
18.409 KILOGRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
