ZCKY52
Limit switch lever, Limit switches XC Standard, ZCKY, glass fiber round 3 mm L=125 mm, -40...120 °C
COMMERCIALISED
Expand all
Datasheet
Series name
STANDARD FORMAT
Product or component type
LIMIT SWITCH LEVER
Device short name
ZCKY
Product compatibility
XCKJ
Movement of operating head
ROTARY
Type of operator
Rod lever spring return glass fiber (round rod 3 mm, L = 125 mm)
Type of approach
LATERAL APPROACH
Switch actuation
BY ANY MOVING PART
Positive opening
WITHOUT
Environmental characteristic
HIGH TEMPERATURE
LOW TEMPERATURE
STANDARD
LOW TEMPERATURE
STANDARD
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
2.0000 CENTIMETER
Package 1 width
1.5000 CENTIMETER
Package 1 length
12.5000 CENTIMETER
Package 1 weight
15.0000 GRAM
Unit type of package 2
S01
Number of units in package 2
20
Package 2 height
15.0000 CENTIMETER
Package 2 width
15.0000 CENTIMETER
Package 2 length
40.0000 CENTIMETER
Package 2 weight
461.0000 GRAM
