9007FTUB4

9007

Universal foundry switch

Severe duty foundry

Limit switch

9007T/FT

Fixed

Rotary head

Style B

Cast zinc

By the body

Rotary

Spring return without operating lever

CW and CCW
from left or right

Silver flashed copper

Snap action

Neutral position

Lateral approach

Without

Screw-clamp terminals AWG 22...AWG 12

1 entry for 1/2" - 14 NPT conforming to ANSI B1.20.1

SPDT-DB

Form Z

Not applicable

+/- 0.004 in linear travel of cam on 1.5 in lever arm

A600, AC (Ue = 600 V) Ie = 5 A conforming to NEMA rating designation, A600, AC (Ue = 480 V) Ie = 6.25 A conforming to NEMA rating designation, A600, AC (Ue = 240 V) Ie = 12.5 A conforming to NEMA rating designation, A600, AC (Ue = 120 V) Ie = 20 A conforming to NEMA rating designation, P600, DC (Ue = 600 V) Ie = 0.2 A conforming to NEMA rating designation, P600, DC (Ue = 250 V) Ie = 1 A conforming to NEMA rating designation, P600, DC (Ue = 120 V) Ie = 5 A conforming to NEMA rating designation

A (left side contact)
B (right side contact)

Corrosion resistant gray paint

30 gn for 9 ms conforming to IEC 60068-2-27

10 gn (f= 10-55 Hz) conforming to IEC 60068-2-6

NEMA 1 conforming to Nema type 250, NEMA 2 conforming to Nema type 250, NEMA 4 conforming to Nema type 250, NEMA 12 conforming to Nema type 250, NEMA 13 conforming to Nema type 250

IP67 conforming to IEC 60529

Class 0 conforming to IEC 61140

PCE

1

7.874 CENTIMETER

9.652 CENTIMETER

16.51 CENTIMETER

1.134 KILOGRAM

1
