XY2CE2A470

Telemecanique Emergency stop rope pull switches XY2C

Latching emergency stop rope pull switch

XY2CE

Red RAL 3000

Class I conforming to IEC 61140, class I conforming to NF C 20-030

Without pilot light

Zamak

Stainless steel

By key-release push-button

421

2 NC

Slow-break

LH side

Screw clamp terminal, 1 x 0.5...2 x 1.5 mm²

Can reach PL = e with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach category 4 with the appropriate monitoring system and correctly wired conforming to EN/ISO 13849-1, can reach SIL 3 with the appropriate monitoring system and correctly wired conforming to EN/IEC 61508

B10d = 300000 conforming to IEC 60947-5-5 value given for a life time of 20 years limited by mechanical or contact wear

CE

With conforming to IEC 60947-5-1

25 MOhm conforming to IEC 60255-7 category 3, 25 MOhm conforming to NF C 93-050 method A

(11-22)NC
(21-22)NC

XY2CE

CSA C22.2 No 14
IEC 60204-1
IEC 60947-5-1
IEC 60947-5-5
ISO 13850
machinery directive 2006/42/EC
UL 508
work equipment directive 2009/104/EC

UL category NISD emergency stop devices, CSA, CCC

TC

10 gn (f= 10-300 Hz) conforming to IEC 60068-2-6

50 gn 11 ms conforming to IEC 60068-2-27

IP65 conforming to IEC 60529

PCE

1

S02

2

15 CENTIMETER

30 CENTIMETER

40 CENTIMETER

3.645 KILOGRAM

1
