XZCPA1241L20
Pre wired connect PVC 4 W M12 female elbowed
Commercialised
Expand all
Datasheet
Accessory / separate part category
Cabling accessory
Accessory / separate part type
Pre-wired connectors
Electrical connection
Elbowed female connector M12, 4 pins
Collar material
Stainless steel 316L
Cable composition
4 x 0.34 mm²
Wire insulation material
PVC
[Ue] rated operational voltage
250 V AC, 300 V DC
Insulating resistance
1 GIGAOHM
IP degree of protection
IP69K
Unit type of package 1
PCE
Number of units in package 1
1
Package 1 height
6 CENTIMETER
Package 1 width
19 CENTIMETER
Package 1 length
12 CENTIMETER
Package 1 weight
11.68 KILOGRAM
Unit type of package 2
BAG
Number of units in package 2
20
Package 2 height
19 CENTIMETER
Package 2 width
19 CENTIMETER
Package 2 length
12 CENTIMETER
Package 2 weight
11.68 KILOGRAM
Indivisible sale quantity
1
California proposition 65
WARNING: This product can expose you to chemicals including: Diisononyl phthalate (DINP), which is known to the State of California to cause cancer, and Di-isodecyl phthalate (DIDP), which is known to the State of California to cause birth defects or other reproductive harm. For more information go to www.P65Warnings.ca.gov
